DH361NGK Eaton 30 Amps 3 Pole HD Fusible Safety Switch 600 Volts Withneut Nema 1

E A T D H361 N G K

DH361NGK Eaton 30 Amps 3 Pole HD Fusible Safety Switch 600 Volts Withneut Nema 1

Coburn's Product #: EATDH361NGK

Mfg#: DH361NGK

Brand: Eaton

Description

Eaton Heavy duty single-throw fused safety switch, 30 A, NEMA 1, Painted steel, Class H, Fusible with neutral, Three-pole, Four-wire, 600 V, Max Hp: 7.5, 10/ 15, 20 hp (1/3PH @480, 600 V), #14-#2 Cu/Al

Attributes

  • Type: Disconnect
  • Amp: 30 Amps
  • Country Of Origin: United States of America
  • Length: 16.5
  • Width: 9.5000
  • Voltage: 600 Volts

Resources

  • Eaton Heavy duty single-throw fused safety switch, 30 A, NEMA 1, Painted steel, Class H, Fusible with neutral, Three-pole, Four-wire, 600 V, Max Hp: 7.5, 10/ 15, 20 hp (1/3PH @480, 600 V), #14-#2 Cu/Al

    • Type: Disconnect
    • Amp: 30 Amps
    • Country Of Origin: United States of America
    • Length: 16.5
    • Width: 9.5000
    • Voltage: 600 Volts
